1 KW Pure Sine Wave inverter with 500W PV

(2 customer reviews)

R4799,00 R4799,00

1000VA/1000W Pure Sine wave inverter charger -12V 500W PV

1000 Watt 12V Pure Sinewave Hybrid Inverter with 40 Amp Charger and 150 VDC MPPT Regulator max 500V PV Hybrid Inverter means you can use it for all possible Solutions, you can use it where you have no Incoming power source, you will have to add Solar panels ( 2 x 250W ) You can use it as UPS, perfect in out current situations with Load shedding. Your Electrician install it next to your DB Box, you can select a few point like your lights, a few plus where TV, Alarm, Gate Motor etc. where by the power coming in will charge the batteries if you put no Solar panels or if the Solar panels doesn’t get enough sun or at night. As soon as there is power Failure or load shedding the transfer switch will simply changeover and the Inverter use the 12V DC and Inverter it to 230 VDC without you even realizing it. As soon as Power failure or Load shedding comes back the Inverter will simply change over back to normal and start charging the batteries is no Solar input is present. If you install the Solar panels is can also be set that it use the PV coming in after batteries are fully charged to use the PV voltage to be used as incoming source and saving you electricity. Other bigger models is also available 2 KW 24V 3 KW 24V 5 KW 48V

SKU: RCT-AXVM1-1K12V Categories: ,
This is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operations such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
Features
Pure sine wave inverter
Built-in MPPT solar charge controller
Configurable input voltage range for home appliances and personal computers via LCD setting
Configurable battery charging current based on applications via LCD setting
Configurable AC/Solar Charger priority via LCD setting
Compatible to mains voltage or generator power
Auto restart while AC is recovering
Overload/ Over temperature/ short circuit protection
Smart battery charger design for optimized battery performance
Cold start function
Basic System Architecture
The following illustration shows basic application for this inverter/charger. It also includes following devices to have a complete running system:
Generator or Utility.
PV modules (option)
Consult with your system integrator for other possible system architectures depending on your requirements.
This inverter can power all kinds of appliances in home or office environment, including motor-type appliances such as tube light, fan and refrigerator.
