In the pursuit of sustainable energy solutions, the installation of solar panels in public spaces has become increasingly common. However, with this eco-friendly initiative comes a significant responsibility that cannot be overlooked. Neglecting damaged solar panels in areas frequented by the public, such as shopping centers, hospitals, and schools, can have severe consequences, ranging from public safety hazards to legal liabilities. Here are essential considerations that underscore the responsibility of solar panel owners in these spaces:

1. Public Safety Concerns:

In public spaces, the risk of accidents and injuries escalates when damaged solar panels are left unattended and unsecured. Proper fencing and security measures are crucial to prevent unintentional contact and ensure the safety of individuals within the vicinity.

2. Electrocution Hazards:

Damaged solar panels in public areas can expose people to the risk of electrocution, especially if live electrical components become accessible due to the damage. This danger is exacerbated in wet conditions, where rainwater can create a conductive path, increasing the potential for electric shocks.

3. Fire Hazards in Public Spaces:

The possibility of a fire stemming from damaged solar panels in a public area poses significant risks to people, property, and the environment. Prompt response to signs of overheating or electrical issues is essential to avert potential fires.

Additional Considerations:

a. Liability Issues:

Neglecting visibly damaged solar panels can lead to legal liabilities. Property owners, maintenance personnel, or system operators may be held accountable if negligence in addressing known issues results in harm or property damage.

b. Regulatory Compliance:

Adhering to local regulations and standards governing the installation and maintenance of solar panels is critical. Failure to comply may result in legal consequences and fines.

c. Emergency Response Challenges:

Emergency response teams may encounter difficulties in dealing with incidents involving damaged solar panels. Proper risk identification and coordination with relevant authorities are vital to effectively mitigate potential harm.

d. Negative Public Perception:

Neglecting damaged solar panels in public areas can lead to negative public perception, damaging the reputation of property owners, operators, or the broader solar industry. Proactive maintenance and swift response demonstrate a commitment to safety and environmental responsibility.

In light of these potential dangers and considerations, addressing any damage to solar panels in public spaces is not just a recommendation; it is a responsibility. Regular inspections, immediate action upon discovering damage, and collaboration with professionals are essential to ensure public safety, regulatory compliance, and the preservation of a positive public image. Clear signage and barriers play a pivotal role in minimizing unauthorized access to damaged solar panels, further enhancing safety in public areas. The journey towards sustainable energy must be accompanied by a steadfast commitment to safety and responsibility, ensuring a brighter future for all.

The global surge in solar energy adoption, encompassing residential and commercial sectors, brings us closer to a sustainable future. Despite this positive trend, the challenges inherent in manufacturing, transportation, and the ongoing evolution of solar technologies demand our attention, particularly when it comes to damaged solar panels. Ensuring the safety of lives, protecting properties, and safeguarding the longevity of renewable energy investments is paramount.

Understanding Solar Panels:

Before we delve into the risks associated with damaged solar panels, let’s establish crucial facts about these energy-generating marvels:

1. Photovoltaic (PV) cells, the foundation of solar panels, harness energy directly from sunlight without the need for chemicals or moving parts.
2. Solar panels operate continuously in the presence of light, and their output remains active, unable to be switched off.
3. Generating Direct Current (DC), solar panels behave differently from Alternating Current (AC), potentially creating a substantial arc during disconnection or short-circuiting.
4. Configured in series and parallel, solar panels result in high DC voltage and current throughout the system.

Risks Associated with Damaged Solar Panels:

This article focuses on visible damages caused by external factors such as hailstorms, fallen trees, vehicle collisions, or structural failures, all of which pose significant risks:

1. Arcing Hazards: Damaged panels may initiate arcing, leading to high temperatures that can rapidly escalate into a fire due to the continuous nature of DC arcs.
2. Melting and Toxic Materials: High-temperature DC arcs can melt the glass, releasing toxic materials used in solar panels. The resulting droplets may cause further damage to the roof structure and become a real fire hazard.
3. Detection Challenges: Damaged panels may go undetected in their early stages. Although inverters often have arc fault detection, it occurs only at the inverter, potentially allowing the spread of fire.
4. Electrocution Risks: Exposure to wet conditions can lead to energy jumps onto structures, presenting a risk of electrocution. While proper earthing is essential, certain situations may still pose a risk.

Case Study: The Shopping Mall in South Africa

To highlight the severity of these risks, consider the case of a shopping mall in South Africa. Disturbingly, after photographs were taken and brought to the mall’s management’s attention, no immediate action was taken. The damaged solar panels posed a potential fire hazard, and the lack of awareness regarding DC voltage risks was evident. This real-life example exemplifies the prevalent misconception that DC voltage is harmless and underscores the urgent need for industry-wide education on the risks associated with damaged solar panels.

Solution: Implementing Height Restrictions with Boom Gates

To address such risks in areas prone to vehicle damage, a practical solution involves implementing height restrictions with boom gates at entrances to parking areas where solar carport arrays are installed. This preventative measure serves as a physical barrier, preventing oversized vehicles from entering and causing damage to the solar panels. Much like the boom gates found in underground parking lots, this solution ensures that vehicles exceeding height limits are unable to access spaces where the carport arrays are installed, significantly reducing the likelihood of damage.

Addressing the Risks and Ensuring Safety:

1. Education is Key: Both installers and system owners must be educated about potential risks, fostering awareness to prevent dangerous incidents such as fires and electrocutions.
2. Regular Inspections: Periodic inspections by qualified professionals are necessary to identify and address any damages promptly.
3. Emergency Response Plans: Develop and communicate emergency response plans to mitigate the impact of incidents like fires or floods.
4. Height Restrictions and Boom Gates: Implementing height restrictions, such as boom gates in parking spaces, can prevent damages caused by oversized vehicles, ensuring a safer environment for solar installations.

Solar energy’s promise for a sustainable future is substantial, but understanding and managing associated risks are imperative. By recognizing the dynamics of solar panels and proactively addressing visible damages, coupled with innovative solutions like height restrictions with boom gates, we can ensure the safety of individuals and the investments made in renewable energy systems. The shopping mall example serves as a stark reminder of the need for education, awareness, and preventive measures to create a secure and thriving solar energy industry.

We’re delighted to share some highlights and resources from our recent webinar, “PV Safety – Risk and Solutions for First Responders,” hosted by PVStop International in collaboration with esteemed presenters, Jim Foran, Director (Australia), and Alex Keene, European Sales & Marketing Manager.

Key Takeaways:

• The webinar shed light on the critical importance of safety in the fast-growing PV industry.
• Emphasis on adherence to regulations and standards for secure PV system installations.
• Identification and mitigation of potential risks, both in direct fire scenarios and situations indirectly involving solar panels.
• Insightful discussions on the role of first responders in addressing incidents related to PV systems swiftly and safely.

Special Thanks: We extend our heartfelt gratitude to Jim Foran and Alex Keene for their valuable insights and expertise. Their contributions made the webinar both informative and engaging.

Access to Recorded Webinar: For those who couldn’t join us live or wish to revisit the valuable content, we’ve made the recorded webinar available. Simply follow this YouTube link to access the full session at your convenience.

Acknowledgment to Attendees: A sincere thank you to all attendees who actively participated in the webinar. Your commitment to safety and engagement in this critical dialogue is essential for creating a safer environment within the PV industry.

We look forward to your continued interest and participation in future webinars. If you have any questions or suggestions for topics you’d like us to cover, please don’t hesitate to reach out.

Stay tuned for more exciting updates and advancements in the world of PV technology!

PV Solar Safety – Risk and Solutions for First Responders 5 December’23 09H00 SouthAfrican Time

The world of solar energy is undergoing a transformative surge, exemplified by the rooftop solar PV capacity in South Africa experiencing an extraordinary 349% increase in just over a year. Anton Eberhard, a prominent South African energy expert, has highlighted this significant growth, emphasizing the need for heightened awareness and stringent safety measures.

Unveiling the Numbers: A Sharp Rise in PV Fires

Despite a 10.5% growth in solar capacity from 2019 to 2022, a concerning trend emerges – a worldwide percentage of nearly 50% surge in solar panel-related fires during the same period. This alarming statistic raises crucial questions about the overall safety of PV installations, particularly as the market saw an influx of untrained companies turned solar installers due to soaring demand.

The Root of the Issue: Untrained Installers and Subpar Workmanship

The rapid expansion of the solar market has led to an influx of untrained companies entering the field. With demand outpacing supply, corners were cut, resulting in improper tool usage, incorrect components and wiring, and subpar workmanship. The repercussions of this trend are far-reaching, creating a long list of potential hazards.

Understanding the Fire Risk Landscape

Each PV installation becomes an integral part of any potential fire incident, necessitating a comprehensive evaluation of potential risks. With a conservative fire risk rate of 0.01%, the looming question is how many fire incidents might unfold in 2024.

The Unseen Threat: DC Danger Zones and First Responder Challenges

Amid this rising concern, a significant challenge arises for first responders. A 5% prevalence of homes and businesses equipped with PV installations magnifies the risk. First responders, trained to combat fires aggressively, face delays due to the inherent dangers associated with DC danger zones, potentially leading to electrocution.

Critical Seconds: The Thin Line Between Control and Catastrophe

The urgency of the matter lies in the critical seconds that can make all the difference between successfully controlling a fire and facing total destruction. The complexity of PV systems, coupled with the lack of expertise during emergency situations, creates a challenging scenario for first responders.

A Call for Vigilance and Expertise

As we witness the rapid expansion of solar energy, it is imperative to prioritize fire safety in PV systems. Ensuring proper training, adherence to safety standards, and the implementation of robust emergency protocols can mitigate the risks associated with the growing number of PV installations. The potential consequences of overlooking this issue are too severe to ignore, emphasizing the need for a collective effort to navigate these challenges and secure a safer energy future.

Introducing PVSTOP: A Solution for Safe De-Energizing

In the face of these challenges, a crucial solution emerges – PVSTOP. This innovative system enables easy and effective de-energizing of PV systems, especially crucial in cases where fires are initiated by DC arcs within the system. De-energizing the PV system simplifies firefighting efforts by eliminating the presence of the DC arc that can reignite flames persistently.

The high temperatures associated with DC arcs pose a significant risk, and attempting to extinguish fires without proper de-energization can result in water damage and a heightened risk of electrocution. Untrained individuals should never attempt this, even with correct safety wear. For first responders, PVSTOP provides a safer and more efficient means of handling PV-related fire incidents, ensuring that critical seconds are maximized for effective intervention.

As we navigate the challenges posed by the growth in PV systems, integrating solutions like PVSTOP becomes paramount. It’s not just about expanding our energy capabilities; it’s about doing so responsibly, with an unwavering commitment to safety, expertise, and a collective effort to secure a resilient and secure energy future.

Date: 5th December 2023 | Time: 09:00 South Africa Time

Introduction:

The global push for renewable energy, driven by initiatives such as the UN 2030 targets to reduce CO2 emissions, has seen remarkable progress. However, as we approach the end of 2023, challenges persist, with load shedding issues in countries like South Africa. The solar industry, in particular, has experienced exponential growth, installing a staggering 4500MW of PV systems in the first 9 months of the year. Amidst this growth, it’s crucial to address safety concerns for first responders, who play a pivotal role in emergencies involving photovoltaic (PV) systems.

The Need for PV Safety:

While the statistics on fires within PV systems are minimal, even a small percentage can result in a significant number of incidents globally. The evolving regulations and constant influx of new products into the market demand a focus on the safety of those responding to emergencies involving PV installations. In the fast-paced world of solar technology, it’s essential to equip first responders with the means to rapidly and safely de-energize PV systems.

Webinar Focus: PV Safety – Risks and Solutions for First Responders

On the 5th of December 2024, at 09:00 South Africa Time, PV industry experts Jim Foran, Director at PVStop International Pty Ltd (Australia), and Alex Keene, European Sales & Marketing Manager at PVStop International Pty Ltd (UK), will host a webinar titled “PV Safety – Risks and Solutions for First Responders.” With their extensive experience collaborating with first responders globally, they will shed light on the challenges faced and present an innovative solution: PVSTOP.

About PVSTOP:

PVSTOP is a cutting-edge light-blocking compound designed to rapidly, effectively, and safely de-energize PV arrays. Already in use by several fire brigades worldwide, PVSTOP ensures that first responders can perform their duties without unnecessary risks associated with PV system emergencies.

Webinar Details:

• Date: 5th December 2024
• Time: 09:00 South Africa Time
• Presenters: Jim Foran (PVStop International Pty Ltd, Australia) and Alex Keene (PVStop International Pty Ltd, UK)
• Topic: PV Safety – Risks and Solutions for First Responders
• Q&A Session: A chance for participants to engage with the experts after the presentation

Who Should Attend:

This webinar is a must-attend for anyone involved in the renewable energy sector (installation or distribution), individuals with PV systems on their premises (commercial or residential), professionals in the insurance, fire and safety industries, and, most importantly, first responders. The insights shared will be invaluable for anyone looking to enhance their understanding of PV safety.

Looking Ahead: PV Safety Conference in March 2024

This webinar serves as a precursor to our larger initiative – a PV Safety Conference scheduled for March 2024 in South Africa. The conference will focus on education, prevention, and the safety of first responders. Registration for the conference will be available in February 2024.

Join our upcoming webinar on Solar PV Safety and Risks! Discover how to ensure the safety and security of solar panels and renewable energy systems. Learn about the crucial differences between AC and DC current and how to minimize associated risks. We’ll explore the importance of quality DC components and their role in preventing issues during installation.

Hot connections and workmanship are also key concerns in PV systems, with MC4 connectors being a potential risk. Find out how you can mitigate these risks with additional safety attachments for MC4 connectors.

Discover solutions that enhance the safety of PV systems, making them safer for first responders and users. Our experts will discuss methods to de-energize solar panels and reduce the “DC Danger Zone.”

First responders and the insurance industry face unique challenges with the growth of solar installations. Learn about effective solutions and best practices to manage risks. We’re excited to offer a webinar in mid-November to raise awareness without a commercial product focus.

In conclusion, we are committed to improving safety in the world of solar PV systems. Join us to gain valuable insights and contribute to a safer environment for all stakeholders. Your participation will make a significant impact in ensuring the safety of everyone involved. Don’t miss out on this important event!

We will confirm the possibility and available date and time as soon as possible and send out invitations to register for this free and informative webinar.

Solar energy is an investment that offers numerous benefits, but its proper setup and maintenance are key to maximizing those advantages. In this detailed guide, we will explore the essential aspects of sizing fuses and Mini DC Non-Polarity Circuit Breakers (MCBs) in your PV Combiner box. We’ll use an 8kW inverter with a 10,400W MPPT capacity as an example to help you understand the process better.

Sizing Fuses for the PV Combiner Box

The fuse is a crucial component in your solar PV system as it safeguards against overcurrent, providing protection to both your equipment and your investment. Let’s use the specifications of 550W panels with 11A Imp and 43V Vmp as an example:

Formula for Fuse Size:

Fuse Size (Amps) = Total Current of the String

One often underestimated but vitally important component is the DC fuse. Surprisingly, it’s become common practice for some installers to use AC fuses in DC circuits, despite the fundamental differences between AC and DC circuits, particularly regarding arc faults. DC arcs are more persistent and harder to extinguish, which is why the use of AC fuses in DC circuits poses significant risks. To tackle this challenge, some installers opt for oversized fuses, thinking they offer more protection. However, this can be counterproductive, as oversized fuses can lead to excessive current flow, potentially damaging your system.

The key to safety and reliability lies in using quality DC fuses that are correctly sized for your system’s specifications. For example, if you have an array of 550W panels with 11A Imp connected in series, selecting a 15A DC fuse would be the most appropriate choice. This ensures that your system’s current doesn’t exceed safe levels while protecting your equipment and warranty. Furthermore, it’s essential to choose the right DC fuse to protect sensitive components like Maximum Power Point Tracking (MPPT) chargers. Opting for the right-sized DC fuse safeguards your investment, ensuring your solar PV system operates safely and efficiently for years to come. Remember, quality DC fuses matter—don’t compromise on the safety and protection of your solar installation.

Mini DC Non-Polarity Circuit Breakers (MCBs)

When it comes to choosing circuit breakers for your solar PV system, understanding the difference between Polarity Breakers and Non-Polarity Breakers is crucial for ensuring both safety and efficiency.

• Polarity Breakers

Polarity Breakers are designed primarily for use in AC circuits. They rely on the direction of current flow to operate correctly. If installed incorrectly, where the current flows in the opposite direction, these breakers can become ineffective and even hazardous. In the context of solar systems, where current direction can change due to factors like shading or partial panel coverage, the use of Polarity Breakers can introduce unnecessary risks.

• Non-Polarity Breakers

Non-Polarity Breakers are specifically engineered for DC circuits, making them ideal for use in solar PV systems. Unlike their Polarity counterparts, Non-Polarity Breakers do not depend on the direction of current flow. This characteristic ensures their reliability and effectiveness, regardless of current direction.

One of the key features that sets Non-Polarity Breakers apart is the presence of an arcing chamber. This specialized chamber serves a vital role in distinguishing and safely extinguishing DC arcs—a challenge unique to DC circuits. DC arcs are more persistent and harder to extinguish than AC arcs, making the arcing chamber an essential safety feature

Non-Polarity Breakers are not just about safety; they also offer comprehensive protection. These breakers feature overload protection to prevent excessive current flow, short circuit protection to swiftly respond to faults, and thermal trip mechanisms to safeguard against overheating. This multifaceted protection ensures your solar system’s longevity and performance.

Sizing the MCBs for Safety

To safeguard your solar PV system effectively, choosing the right amp rating for Mini DC Non-Polarity Circuit Breakers (MCBs) is crucial. In our example, with 550W panels and a constant current of 11A per string, selecting 11A MCBs aligns with best practices for system protection. However, the most common choice for MCBs in this scenario is 16A DC Non-Polarity Breakers. This slightly higher rating offers an added layer of protection, ensuring that your system remains safe while accommodating potential minor variations in current.

n summary, while Polarity Breakers have their place in AC circuits, Non-Polarity Breakers are the unequivocal choice for DC circuits, particularly in solar PV systems. These specialized breakers not only ensure consistent and reliable protection but also boast an arcing chamber to safely handle DC arcs. With overload protection, short circuit protection, and thermal trip mechanisms, Non-Polarity Breakers are the complete package, guaranteeing the safety, performance, and longevity of your solar investment. By making informed choices, you empower your solar system to operate seamlessly and securely, delivering on the promise of clean and sustainable energy.

DC Surge Protectors

Protecting your system from voltage surges is essential for its longevity and performance. To safeguard against these potential threats:

• Install a DC surge protector for each string, connecting them in parallel before the MCB for that string.
• Ensure that the surge protectors are rated for the voltage range of your system, which, in this case, is 125 – 425Vdc
• Verify that they have appropriate surge protection capabilities to effectively neutralize voltage spikes, preserving your equipment.

Earth Wire and Bonding

Proper grounding is critical to the safety and functionality of your solar PV system. Here are the key considerations:

• Size the earth wire according to local electrical codes and standards to meet safety requirements.
• Securely connect the earth bar to the ground, establishing a reliable electrical connection.
• Bond the panels’ earth wires to the earth bar, ensuring that potential differences are properly managed.
• Route the earth wire as directly and as straight as possible to minimize resistance and guarantee effective grounding.

Conclusion

In summary, sizing fuses and MCBs correctly is essential to ensure the safe and efficient operation of your solar PV system. Using an 8kW inverter with a 10,400W MPPT capacity as an example, we’ve outlined the calculations and steps necessary to determine the appropriate fuse and MCB sizes for your PV Combiner box. Additionally, we’ve highlighted the importance of DC surge protectors and proper grounding to protect your system and maintain its performance.

By following these guidelines and adhering to local electrical codes and standards, you’ll not only safeguard your investment but also ensure that your solar PV system operates safely and efficiently for years to come. Remember, the safety and longevity of your solar installation depend on the proper selection and sizing of these critical components.
